Applications: Civil Engineering Mines, quarries, coal ore and slurries Sewage Treatment plants General pumping purposes Specification: Water temperature : upto 45°C Power Supply : Three phase 380V ±10%,50Hz Power : 1.5 to 15Kw Insulation Class: F Protection Class : IP68 Capacity : upto 156 m3/h Head : upto 56 m Maximum immersion depth : 50 m PH : 6.5 to 8.5 Cable length : 8 m Function and feature: Compact design, high performance and exceptional durability for handling abrasive liquid, widely used in general construction and civil engineering. The body of motor and pump is made of rigid cast iron or stainless steel for long-lasting durability. Greatly increased maximum submersion depth due to mechanical seal resistance to high pressure (0.5Mpa) Semi-open impeller made of high chrome alloy/ SS 304 match with wear plate (ductile iron) achieves superior durability. Effective motor cooling due to discharge channel cast iron as part of the motor housing. Space economy by a top outlet. Hermetically sealed motor equip build-in thermal protection. The protector in the motor can automatically cut off the power when it overheats or over current.
